Mainboard Gigabyte Z790 Gaming X AX – Socket Intel LGA 1700

0 lượt xem |
Thương hiệu: Intel
|
Loại: Mainboard
6,790,000₫ 7,990,000₫
Tiêu đề:
Chọn gói khuyến mãi
ProductInfo
Mainboard Gigabyte Z790 Gaming X AX - chính hãng giá rẻ tại Xgear. Chất lượng linh kiện cao cấp, bảo hành chính hãng.
  • Nhập mã VNPAYICT giảm 3% tối đa 100.000đ cho đơn từ 500.000đ khi thanh toán qua VNPAY
Cam kết bán hàng
  • Hàng chính hãng.Mới 100% Hàng chính hãng.Mới 100%
  • Hỗ trợ trả góp Hỗ trợ trả góp
  • Giao hàng ngay (nội thành HN & TP.HCM) Giao hàng ngay (nội thành HN & TP.HCM)
  • Đổi trả trong 7 ngày đầu nếu có lỗi phần cứng từ NXS. Đổi trả trong 7 ngày đầu nếu có lỗi phần cứng từ NXS.
ProductInfo
Mainboard Gigabyte Z790 Gaming X AX - chính hãng giá rẻ tại Xgear. Chất lượng linh kiện cao cấp, bảo hành chính hãng.
Mô tả sản phẩm

Bảo hành chính hãng 36 tháng

Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700

Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700

Mainboard Gigabyte Z790 Gaming X AX

Thông số kỹ thuật Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700

  • CPU Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700 :
    LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
    L3 cache varies with CPU
    (Please refer “CPU Support List” for more information.)
  • Chipset Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700 :
    Intel® Z790 Express Chipset
  • Bộ nhớ Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700:
    Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules
    4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)
  •  Card đồ họa tích hợp Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700
    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.0 version and HDCP 2.3.
    2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60
      * Support for DisplayPort 1.2 version and HDCP 2.3

    (Graphics specifications may vary depending on CPU support.)

  • Âm thanh Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700
    Realtek® Audio CODEC
    High Definition Audio
    2/4/5.1/7.1-channel
    * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
    Support for S/PDIF Out
  • LAN Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700
    Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Wireless Communication module
    Intel® Wi-Fi 6E AX211
    WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    BLUETOOTH 5.3
    Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    * Actual data rate may vary depending on environment and equipment.
  • Khe cắm mở rộng Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700:
    CPU:
    1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
    * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    Chipset:
    2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)
    Support for AMD CrossFire™ technology (PCIEX16 and PCIEX4)
  • Giao diện lưu trữ Mainboard Gigabyte Z790 Aorus Elite AX DDR4 - Socket Intel LGA 1700
    CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
    Chipset:
    2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB)
    1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB)
    6 x SATA 6Gb/s connectors
    RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devicesRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
    * Refer to “2-8 Internal Connectors,” for the installation notices for the M.2 and SATA connectors.
  • USB Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700
    1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support
    1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
    Chipset+2 USB 2.0 Hubs:
    8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
  • Kết nối I/O bên trong Mainboard Gigabyte Z790 Gaming X AX - Socket Intel LGA 1700
    1 x 24-pin ATX main power connector
    2 x 8-pin ATX 12V power connectors
    1 x CPU fan header
    1 x water cooling CPU fan header
    3 x system fan headers
    1 x system fan/water cooling pump header
    2 x addressable LED strip headers
    2 x RGB LED strip headers
    4 x M.2 Socket 3 connectors
    6 x SATA 6Gb/s connectors
    1 x front panel header
    1 x front panel audio header
    1 x USB Type-C® header, with USB 3.2 Gen 2 support
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    2 x Thunderbolt™ add-in card connectors
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    1 x reset button
    1 x Q-Flash Plus button
    1 x Clear CMOS button
    1 x reset jumper
    1 x Clear CMOS jumper
  • Kết nối bảng phía sau
  • 1 x USB Type-C® port, with USB 3.2 Gen 2×2 support
  • 2 x USB 3.2 Gen 2 Type-A ports (red)
  • 3 x USB 3.2 Gen 1 ports
  • 4 x USB 2.0/1.1 ports
  • 2 x SMA antenna connectors (2T2R)
  • 1 x HDMI 2.0 port
  • 1 x DisplayPort
  • 1 x RJ-45 port
  • 1 x optical S/PDIF Out connector
  • 2 x audio jacks
  • Điều khiển I/O
    iTE® I/O Controller Chip
  • Theo dõi phần cứng
    Voltage detection
    Temperature detection
    Fan speed detection
    Water cooling flow rate detection
    Fan fail warning
    Fan speed control
    * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
  • BIOS
    1 x 256 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Tính năng duy nhất
    Support for GIGABYTE Control Center (GCC)
    * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    Support for Q-Flash
    Support for Q-Flash Plus
    Support for Smart Backup
  • Hệ điều hành
    Support for Windows 11 64-bit
    Support for Windows 10 64-bit
  • Hệ số khuôn
    ATX Form Factor; 30.5cm x 24.4cm
